Description
From the Gun Digest Book of Gun Drawings, this 54-page Digital PDF download contains the isometric, exploded drawings for 53 Winchester Long Guns. The download is the perfect aid for anyone looking to identify and order replacement parts, or take a gun apart for cleaning and simple repair. Models in this download include:
- Winchester Model 1 Super X Autoloading Shotgun
- Winchester Model 100 Autoloading Rifle
- Winchester Model 101 Over/Under Shotgun
- Winchester Model 12 Slide-Action Shotgun
- Winchester Model 1200 Slide-Action Shotgun
- Winchester Model 121 and 131 Bolt-Action Rifle
- Winchester Model 1300 XTR Slide-Action Shotgun
- Winchester Model 1400, 1400 Mark II and Ranger Autoloading Shotgun
- Winchester Model 141 Bolt-Action Rifle
- Winchester Model 150 and 190 Lever-Action Rifle
- Winchester Model 1500 XTR Autoloading Shotgun
- Winchester Model 1873 Lever-Action Rifle
- Winchester Model 1885 Single Shot Rifle
- Winchester Model 1886 Lever-Action Rifle
- Winchester Model 1892 Lever-Action Rifle
- Winchester Model 1897 Slide-Action Shotgun
- Winchester Model 1905 Autoloading Rifle
- Winchester Model 1907 Autoloading Rifle
- Winchester Model 43 Bolt-Action Rifle
- Winchester Model 21 Side-by-Side Shotgun
- Winchester Model 23 XTR Side-by-Side Shotgun
- Winchester Model 24 Side-by-Side Shotgun
- Winchester Model 25 Slide-Action Shotgun
- Winchester Model 250, 255, 270, 275 and 290 Lever-Action Rifle
- Winchester Model 310 and 320 Bolt-Action Rifle
- Winchester Model 37A, 370 and 840 Single Shot Shotgun
- Winchester Model 490 Autoloading Rifle
- Winchester Model 50 and 59 Autoloading Shotgun
- Winchester Model 52B Target and Sporting Bolt-Action Rifle
- Winchester Model 52C Target and Sporting Bolt-Action Rifle
- Winchester Model 52D Target Bolt-Action Rifle
- Winchester Model 55 Autoloading Rifle
- Winchester Model 61 Slide-Action Rifle
- Winchester Model 62A Slide-Action Rifle
- Winchester Model 63 Autoloading Rifle
- Winchester Model 64A Lever-Action Rifle
- Winchester Model 670A Bolt-Action Rifle
- Winchester Model 69A Bolt-Action Rifle
- Winchester Model 70 and 70 Featherweight Bolt-Action Rifle
- Winchester Model 71 Lever-Action Rifle
- Winchester Model 74 Autoloading Rifle
- Winchester Model 75 Bolt-Action Rifle
- Winchester Model 77 Autoloading Rifle
- Winchester Model 88 Lever-Action Rifle
- Winchester Model 9422 Lever-Action Carbine
- Winchester Model 96 Over/Under Shotgun
- Winchester New Model 70 Lightweight Bolt-Action Rifle
- Winchester New Model 70A and 770 Bolt-Action Rifle
- Winchester New Model 70 XTR Sporter Bolt-Action Rifle
- Winchester New Model 94 Angle Eject Lever-Action Rifle
- Winchester New Model 94 Lever-Action Carbine
- Winchester New Model 94 Top-Eject Lever-Action Rifle
- Winchester Single Shot Rifle
